Portable Power Distribution Boxes: PowerHOUSE™ & PowerRACK™

PowerHOUSE

Lex Products offers a full range of portable power distribution boxes and units, specifically engineered for indoor and outdoor use for the entertainment, industrial and military industries. Our power distribution boxes range from 20-800 Amps and are well known for being durable, long lasting and safe.

Load Master™ Series portable power distribution boxes are the first in the industry to feature outputs with adjustable current ratings to match specific application loads. These temporary power distribution boxes feature 1, 3 or 4 adjustable circuit breakers, with a range of amperage and voltage ratings.

ImageTitlePart NumberDescription

100 Amp Bento Box® Gang Box

100 Amp Bento Box® Gang BoxBNF3-1A2B-10.5

100A 125 VAC, (1) 100A 125 VAC Stage Pin (Bates) Male (Plug) on a 1.5' Pigtail to (5) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Bento™

100 Amp Bento Box® Lunchbox

100 Amp Bento Box® LunchboxBNF2-5A

100A 125 VAC, (1) 100A 125 VAC Stage Pin (Bates) Male (Inlet) to (5) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Bento™

100 Amp LOpSter™ Lunchbox, RDM Splitter

100 Amp LOpSter™ Lunchbox, RDM SplitterPH100W-NDC-15CC-RCAT

100A 125 VAC, (1) 100A 125 VAC Stage Pin (Bates) Male (Inlet) to (5) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets) and (4) USB Type A Receptacles, RDM/DMX Opto-Splitter, Feed Thru, LOpSter™

100 Amp LOpSter™ Lunchbox, Wireless DMX

100 Amp LOpSter™ Lunchbox, Wireless DMXPH100W-NDC-15CC-WCAT

100A 125 VAC, (1) 100A 125 VAC Stage Pin (Bates) Male (Inlet) to (5) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets) and (4) USB Type A Receptacles, Wireless DMX Opto-Splitter, Feed Thru, LOpSter™

100 Amp Pagoda Lunchbox

100 Amp Pagoda LunchboxDBS100FP-B4B2100A 125 VAC, (1) 100 Amp Stage Pin (Bates) Male (Inlet) to (5) NEMA 5-20 (Edison) Receptacles, Feed Thru, Pagoda Jr.

100 Amp Pagoda to Duplex Receptacles

100 Amp Pagoda to Duplex ReceptaclesDB100A-A401520

100A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (15) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Pagoda™

100 Amp Pagoda to Duplex Receptacles, Weather Resistant

100 Amp Pagoda to Duplex Receptacles, Weather ResistantDB100NP-ABB-S3

100A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (15) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Pagoda™

100 Amp Pagoda to GFCI Duplex Receptacles, Weather Resistant

100 Amp Pagoda to GFCI Duplex Receptacles, Weather ResistantDB100NP-AQQ-S3

100A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (12) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets), Pagoda™

100 Amp Pagoda to L21-20 Receptacles

100 Amp Pagoda to L21-20 ReceptaclesDB100NP-AFF-S3

100A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (5) NEMA L21-20 Locking Receptacles (Outlets), Pagoda™

100 Amp Pagoda to L21-20 Receptacles Single Pole

100 Amp Pagoda to L21-20 Receptacles Single PoleDB100N1J5DM-13-SP

100A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (5) NEMA L21-20 Locking Receptacles (Outlets), Pagoda™

100-250 Amp Pagoda Load Master

100-250 Amp Pagoda Load MasterDB250LP-AW-S3

100A-250A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (1) Set of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Pagoda™

100-250 Amp Pagoda™ Load Master

100-250 Amp Pagoda™ Load MasterDB250LP-AWB-S3

100A-250A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (1) Set of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets) and (1) NEMA 5-20 (Edison) Straight Blade Receptacle (Outlet), Pagoda™

100-250 Amp Pagoda™ Load Master

100-250 Amp Pagoda™ Load MasterDB250LP-AW-S3-BOY

100A-250A 277/480Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (1) Set of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Pagoda™

100-250 Amp Pagoda™ Load Master

100-250 Amp Pagoda™ Load MasterDB250LP-AW-S3-BBB

100A-250A 600 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (1) Set of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Pagoda™

100kW Airforce Style Power Distribution Box

100kW Airforce Style Power Distribution Box6110-01-248-6671

Distributes power to smaller distribution units, environmental control units, portable lights and for expeditionary applications including base camps.

1200 Amp Powerstation Jr.™ Motion Picture Box

1200 Amp Powerstation Jr.™ Motion Picture BoxDB400N2J6BC3BD-H1

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) 100A 250 VAC Stage Pin (Bates) Receptacles (Outlets), (6) 100A 125 VAC Stage Pin (Bates) Receptacles (Outlets) and (1) NEMA 5-20 (Edison) Straight Blade Receptacle (Outlet), Feed Thru, Power Station Jr.™

15 Amp Quad Box with 1' Tail

15 Amp Quad Box with 1' TailDB15-QD1-1D

15A 125 VAC, (1) NEMA 5-15 (Edison) Straight Blade Male (Plug) on a 1.0' Pigtail to (2) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Quad Box

15 Amp Quad Box with 25' Tail

15 Amp Quad Box with 25' TailDB15-QD25-1D

15A 125 VAC, (1) NEMA 5-15 (Edison) Straight Blade Male (Plug) on a 25.0' Pigtail to (2) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Quad Box

15kW Airforce Style Power Distribution Box

15kW Airforce Style Power Distribution Box6110-01-236-3829

Distributes power to smaller distribution units, environmental control units, portable lights and for expeditionary applications including base camps.

160 Amp Pagoda RV Box, Weather Resistant

160 Amp Pagoda RV Box, Weather ResistantPH160A3-N1J-24CS2CZ160A 120/208 VAC, (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) NEMA 14-50 Receptacles and (2) TT30 Receptacles, Pagoda

160-400 Amp Pagoda™ Load Master

160-400 Amp Pagoda™ Load MasterDB400LP-AW-S3

160A-400A 600 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (1) Set of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Pagoda™

160-400 Amp Pagoda™ Load Master

160-400 Amp Pagoda™ Load MasterDB400LP-AW-S3-BOY

160A-400A 600 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (1) Sets of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Pagoda™

160-400 Amp Pagoda™ Load Master

160-400 Amp Pagoda™ Load MasterDB400LP-AW-S3-BBB

160A-400A 600 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (1) Set of (5) 16 Series Cam-type, Single Pole Females (Outlets), Pagoda

20 Amp 1RU Enclosed Rack, powerCON® to Duplex Receptacles

20 Amp 1RU Enclosed Rack, powerCON® to Duplex ReceptaclesPRM1TN-6CA

15A 125 VAC, (1) powerCON® A (Blue) Inlet to (6) NEMA 5-15 (Edison) Straight Blade Receptacles (Outlets), Rack Mount Box

20 Amp 1RU Enclosed Rack, powerCON® to Duplex Receptacles

20 Amp 1RU Enclosed Rack, powerCON® to Duplex ReceptaclesPRM1UN-8CA

15A 125 VAC, (1) powerCON® A (Blue) Inlet to (8) NEMA 5-15 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Rack Mount Box

20 Amp Bento Box® Edison Breakout Box

20 Amp Bento Box® Edison Breakout BoxBNZJ2-Z3

20A 120/208 VAC, (1) LSC19 19-Pin Male (Inlet) to (6) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Bento

20 Amp Bento Box® Edison/Stage Pin (Bates) Breakout Box

20 Amp Bento Box® Edison/Stage Pin (Bates) Breakout BoxBNZJ3-Z1

20A 120/208 VAC, (1) LSC19 19-Pin Male (Plug) on a 1.5' Pigtail to (3) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets) and (6) 20A Stage Pin (Bates) Receptacles, Bento­™

20 Amp Bento Box® powerCON® Breakout Box

20 Amp Bento Box® powerCON® Breakout BoxBNZJ2-6M

20A 120/208 VAC, (1) LSC19 19-Pin Male (Inlet) to (6) powerCON® B (Grey) Receptacles (Outlets), Feed Thru, Bento

20 Amp Cube Gang Box

20 Amp Cube Gang BoxDB20-C13GFI

20A 120/208 VAC, (1) NEMA L21-20 Locking Male (Plug) on a 1.5' Pigtail to (3) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets), C06

20 Amp Quad Box powerCON® TRUE1 to Duplex Receptacles

20 Amp Quad Box powerCON® TRUE1 to Duplex ReceptaclesDB20T1-SBPC

20A 125 VAC, (1) powerCON TRUE1® Male Inlet to (2) NEMA 5-20 (Edison) Straight Blade Duplex Receptacles (Outlets), Feed Thru, Quad Box

20 Amp Quad Box powerCON® to Duplex Receptacles

20 Amp Quad Box powerCON® to Duplex ReceptaclesDB20PC-SBPC-TI

20A 125 VAC, (1) powerCON® A (Blue) Inlet to (2) NEMA 5-20 (Edison) Straight Blade Duplex Receptacles (Outlets), Feed Thru, Quad Box

200 Amp

200 Amp "Viceroy" PowerRACK™ to 19-Pin/L21-30/Duplex ReceptaclesPRMK12D-MR4U-2LV-RB

200A 120/208Y VAC, (1) Sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (8) LSC19 19-Pin Receptacle (Outlets) and (3) NEMA L21-30 Locking Receptacles (Outlets) and (6) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Rolling Rack

200 Amp Hammerhead to L21-20 Receptacles

200 Amp Hammerhead to L21-20 ReceptaclesDB200N1J10DM-63

200A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (10) NEMA L21-20 Locking Receptacles, Hammerhead

200 Amp Hammerhead to L21-20 Receptacles

200 Amp Hammerhead to L21-20 ReceptaclesDB200N1J10DM-63-2

200A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (10) NEMA L21-20 Locking Receptacles, Hammerhead

200 Amp Military Style Lex Mobile Power Distribution Box

200 Amp Military Style Lex Mobile Power Distribution BoxDB200MP-PQ66S3

US Army Force Provider Expeditionary Base Camp

200 Amp Pagoda Motion Picture Box

200 Amp Pagoda Motion Picture BoxDB200A-A4061FT

200A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (6) 100A 125 VAC Stage Pin (Bates) Receptacles (Outlets) and (2) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Pagoda™

200 Amp Pagoda Moving Light Box

200 Amp Pagoda Moving Light BoxDB160NP-ADDMS1

200A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (12) NEMA L6-20 Locking Receptacles (Outlets) and (2) LSC19 19-Pin Receptacle (Outlets), Pagoda™

200 Amp Pagoda to 19-Pin Receptacles

200 Amp Pagoda to 19-Pin ReceptaclesDBS200-A4BM2

100A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Plugs) to (4) LSC19 19-Pin Receptacles and (3) NEMA 5-20 (Edison) Duplex Receptacles, Pagoda

200 Amp Pagoda to 50 Amp Locking Receptacles, Weather Resistant

200 Amp Pagoda to 50 Amp Locking Receptacles, Weather ResistantDB200NP-A6S-S3

200A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (6) California Style CS63 Receptacles (Outlets), Pagoda™

200 Amp Power Station Jr. to GFCI Duplex Receptacles, Weather Resistant

200 Amp Power Station Jr. to GFCI Duplex Receptacles, Weather ResistantDB200N1J24CD-H3

200A 120/208 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (24) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets), Power Station Jr.™

200 Amp Power Station to TT-30 RV Receptacles, Weather Resistant

200 Amp Power Station to TT-30 RV Receptacles, Weather ResistantDB200NQ-PTT-S3

200A 120/208 VAC, ((1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (21) TT-30 Straight Blade RV Receptacles (Outlets), Feed Thru, Power Station Jr.™

200 Amp Terrapin Station II™ to 50 Amp Locking Receptacles, Weather Resistant

200 Amp Terrapin Station II™ to 50 Amp Locking Receptacles, Weather ResistantPH200A3-N1J-16DW-T

200A 120/208 VAC, (5) 16 Series Cam-type, Single Pole Males (Inlets) to (6) California Style Locking Receptacles, Terrapin II

200kW Airforce Style Power Distribution Box

200kW Airforce Style Power Distribution Box6110-01-236-5889

Distributes power to smaller distribution units, environmental control units, portable lights and for expeditionary applications including base camps.

25kW Airforce Style Power Distribution Box

25kW Airforce Style Power Distribution Box6110-01-244-3209

Distributes power to smaller distribution units, environmental control units, portable lights and for expeditionary applications including base camps.

30 Amp 1RU Enclosed Rack, powerCON® to Duplex Receptacles

30 Amp 1RU Enclosed Rack, powerCON® to Duplex ReceptaclesPRM1TNTN-8CA

30A 125 VAC, (2) powerCON® A (Blue) Inlets to (8) NEMA 5-15 (Edison) Straight Blade Receptacles (Outlets), Rack Mount Box

30 Amp 2RU Enclosed Rack, L14-30 to L5-30

30 Amp 2RU Enclosed Rack, L14-30 to L5-30PRM2IJ-5CC2DC

30A 125/250 VAC, (1) NEMA L14-30 Locking Male (Inlet) to (2) NEMA L5-30 Locking Receptacles (Outlets) and (5) NEMA 5-20 (Edison) Duplex Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 2RU Enclosed Rack, L14-30 to L5-30/Duplex Receptacles

30 Amp 2RU Enclosed Rack, L14-30 to L5-30/Duplex ReceptaclesPRM2IJ-3CC4DC

30A 125/250 VAC, (1) NEMA L14-30 Locking Male (Inlet) to (4) NEMA L5-30 Locking Receptacles (Outlets) and (3) NEMA 5-20 (Edison) Straight Blade Duplex Receptacles, Feed Thru, Rack Mount Box

30 Amp 2RU Enclosed Rack, L21-30 to Duplex Receptacles

30 Amp 2RU Enclosed Rack, L21-30 to Duplex ReceptaclesPRM2IN-7CC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (7) NEMA 5-20 (Edison) Duplex Straight Blade Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 2RU Enclosed Rack, L21-30 to Duplex Receptacles

30 Amp 2RU Enclosed Rack, L21-30 to Duplex ReceptaclesPRM2IN-9CC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (9) NEMA 5-20 (Edison) Straight Blade Duplex Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 2RU Enclosed Rack, L21-30 to L5-30/Duplex Receptacles

30 Amp 2RU Enclosed Rack, L21-30 to L5-30/Duplex ReceptaclesPRM2IN-3CC4DC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Inlet to (4) NEMA L5-30 Locking Receptacles and (3) NEMA 5-20 Duplex Receptacles, Feed Thru, Rack Mount Box

30 Amp 2RU Enclosed Rack, L21-30 to L5-30/Duplex Receptacles

30 Amp 2RU Enclosed Rack, L21-30 to L5-30/Duplex ReceptaclesPRM2IN-5CC2DC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (2) NEMA L5-30 Locking Receptacles (Outlets) and (5) NEMA 5-20 (Edison) Straight Blade Duplex Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 2RU Enclosed Rack, L21-30 to powerCON®

30 Amp 2RU Enclosed Rack, L21-30 to powerCON®PRM2IN-1CC12GN

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (12) powerCON® B (Grey) Receptacles and (1) NEMA 5-20 (Edison) Straight Blade Duplex Receptacle (Outlet), Feed Thru, Rack Mount Box

30 Amp 2RU Enclosed Rack, L5-30 to Duplex Receptacles

30 Amp 2RU Enclosed Rack, L5-30 to Duplex ReceptaclesPRM2IC-9CC

30A 125 VAC, (1) NEMA L5-30 Locking Resceptcle (Inlet) to (9) NEMA 5-20 (Edison) Straight Blade Duplex Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 3RU Enclosed Rack, L14-30 to Duplex Receptacles

30 Amp 3RU Enclosed Rack, L14-30 to Duplex ReceptaclesPRM3IJ-9CC

30A 125/250 VAC, (1) NEMA L14-30 Locking Male (Inlet) to (9) NEMA 5-20 (Edison) Striaght Blade Duplex Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 3RU Enclosed Rack, L21-30 to Duplex Receptacles

30 Amp 3RU Enclosed Rack, L21-30 to Duplex ReceptaclesPRM3IN-9CC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (9) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 3RU Enclosed Rack, L21-30 to L21-30/Duplex Receptacles

30 Amp 3RU Enclosed Rack, L21-30 to L21-30/Duplex ReceptaclesPRM3IN-1CC6DC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (6) NEMA L5-30 Locking Receptacles (Outlets) and (1) NEMA 5-20 (Edison) Straight Blade Duplex Receptacle (Outlet), Feed Thru, Rack Mount Box

30 Amp 3RU Enclosed Rack, L21-30 to L5-30/Duplex Receptacles

30 Amp 3RU Enclosed Rack, L21-30 to L5-30/Duplex ReceptaclesPRM3IN-3CC4DC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (4) NEMA L5-30 Locking Receptacles (Outlets) and (3) NEMA 5-20 (Edison) Straight Blade Duplex Receptacles, Feed Thru, Rack Mount Box

30 Amp 3RU Enclosed Rack, L21-30 to L5-30/Duplex Receptacles

30 Amp 3RU Enclosed Rack, L21-30 to L5-30/Duplex ReceptaclesPRM3IN-4CC3DC

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (3) NEMA L5-30 Locking Receptacles (Outlets) and (4) NEMA 5-20 Straight Blade Duplex Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 3RU Enclosed Rack, L21-30 to L5-30/Duplex Receptacles

30 Amp 3RU Enclosed Rack, L21-30 to L5-30/Duplex ReceptaclesPRM3IN-5CC2DC

30A 120/208Y VAC, (1) NEMA L21-30 Male (Inlet) to (2) NEMA L5-30 Receptacles and (5) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Rack Mount Box

30 Amp 3RU Enclosed Rack, L21-30 to powerCON®

30 Amp 3RU Enclosed Rack, L21-30 to powerCON®PRM3IN-1CC12GN

30A 120/208Y VAC, (1) NEMA L21-30 Locking Male (Inlet) to (12) powerCON® B (Grey) Receptacles (Outlets) and (1) NEMA 5-20 (Edison) Striaght Blade Duplex Receptacle (Outlets), Feed Thru, Rack Mount Box

30 Amp Bento Box® with Duplex Receptacles

30 Amp Bento Box® with Duplex ReceptaclesBNB2-3B

30A 120/208 VAC, (1) NEMA L21-30 Locking Male (Inlet) to (3) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Bento™

300 Amp CineBox™ Motion Picture Box

300 Amp CineBox™ Motion Picture BoxPH100A1-N1J-33BC2CC1C100A 120/208 VAC, (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) 100A Stage Pin (Bates) Receptacles and (3) NEMA 5-20 (Edison) Receptacles, CineBox

300 Amp Pagoda Jr.™ Motion Picture Box

300 Amp Pagoda Jr.™ Motion Picture BoxDBS100DT-B4BI2

100A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Plugs) on 1.5' Pigtails to (3) 100A 125 VAC Stage Pin (Bates) Receptacles (Outlets) and (3) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Pagoda Jr.™

30kW Airforce Style Power Distribution Box

30kW Airforce Style Power Distribution Box6110-01-236-5890

Distributes power to smaller distribution units, environmental control units, portable lights and for expeditionary applications including base camps.

400 Amp Hammerhead™ Cam Splitter Weather Resistant

400 Amp Hammerhead™ Cam Splitter Weather ResistantDB400N1J4AJ2CC-63

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) Sets of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets) and (2) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Hammerhead™

400 Amp Hammerhead™ Cam Splitter Weather Resistant

400 Amp Hammerhead™ Cam Splitter Weather ResistantDB400N1J4AJ2CD-63

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) Sets of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets) and (2) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets), Hammerhead™

400 Amp Hammerhead™ Cam Splitter Weather Resistant

400 Amp Hammerhead™ Cam Splitter Weather ResistantDB400N1J4AJ-63

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) Sets of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Hammerhead™

400 Amp Hammerhead™ Cam Splitter Weather Resistant

400 Amp Hammerhead™ Cam Splitter Weather ResistantDB400N1J4AJ-63-600Y

400A 600 VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) Sets of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Hammerhead™

400 Amp Power Station Jr™ to 19-Pin and Duplex Receptacles

400 Amp Power Station Jr™ to 19-Pin and Duplex ReceptaclesDB400MP-PMB-B1

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (8) LSC19 19-Pin Receptacle (Outlets) and (3) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Power Station Jr.™

400 Amp Power Station with Casters to California Style Locking Receptacles, Weather Resistant

400 Amp Power Station with Casters to California Style Locking Receptacles, Weather ResistantPH400H3-N2J-1ADW-CW

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (10) California Style CS63 Receptacles (Outlets), Feed Thru, Power Station™ with Casters

400 Amp Spider Box

400 Amp Spider BoxDB400BP-WWW-S3

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (5) Sets of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets), Turtle™

50 Amp 3RU Enclosed Rack, 50 Amp Locking Inlet to Duplex Receptacles

50 Amp 3RU Enclosed Rack, 50 Amp Locking Inlet to Duplex ReceptaclesPRM3KN-9CC

50A 125/250 VAC, (1) California Style CS63 Male (Inlet) to (9) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Rack Mount Box

50 Amp Pagoda Jr.™ to Duplex Receptacles, Feed Thru, Weather Resistant

50 Amp Pagoda Jr.™ to Duplex Receptacles, Feed Thru, Weather ResistantDB-50NQ-BBB-S3

50A 125/250 VAC, (1) California Style CS63 Male (Inlet) to (6) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Pagoda Jr.™

50 Amp Pagoda Jr.™ to GFCI Duplex Receptacles, Weather Resistant

50 Amp Pagoda Jr.™ to GFCI Duplex Receptacles, Weather ResistantDB-50NF-BQQ-S3

50A 125/250 VAC, (1) California Style CS63 Male (Inlet) to (6) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets), Pagoda Jr.™

50 Amp Terrapin Station II™ to Locking Receptacles, Feed Thru 50 Amp Terrapin Station II™ to Locking Receptacles, Feed Thru Spider Box to GFCI L5-20/L6-30 Receptacles

50 Amp Terrapin Station II™ to Locking Receptacles, Feed Thru 50 Amp Terrapin Station II™ to Locking Receptacles, Feed Thru Spider Box to GFCI L5-20/L6-30 ReceptaclesT2-A2-6B1E

50A 125/250 VAC, (1) California Style CS63 Male (Inlet) to (6) NEMA L5-20 Locking Receptacles (Outlets) and (1) NEMA L6-30 Locking Receptacle (Outlet), Feed Thru, Terrapin II™

50 Amp Terrapin Station II™, Feed Thru Spider Box to GFCI Duplex/L6-30 Receptacles

50 Amp Terrapin Station II™, Feed Thru Spider Box to GFCI Duplex/L6-30 ReceptaclesT2-A2-6A1E

50A 125/250 VAC, (1) California Style CS63 Male (Inlet) to (6) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets) and (1) NEMA L6-30 Locking Receptacle (Outlet), Feed Thru, Terrapin II™

60 Amp Bento Box® Gang Box

60 Amp Bento Box® Gang BoxBNE3-3A-10.5

60A 125 VAC, (1) 60A 125 VAC Stage Pin (Bates) Male (Plug) on a 1.5' Pigtail to (3) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Bento ™

60 Amp Bento Box® Lunchbox

60 Amp Bento Box® LunchboxBNE2-5A

60A 125 VAC, (1) 60A 125 VAC Stage Pin (Bates) Male (Inlet) to NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Bento™

60 Amp CineBox™ Lunchbox

60 Amp CineBox™ LunchboxPH060B1-NDB-13CC60A 120 VAC, (1) 60 Amp Stage Pin (Bates) Male (Inlet) to (5) NEMA 5-20 (Edison) Receptacles, Feed Thru, CineBox

600 Amp CineBox™ Motion Picture Box

600 Amp CineBox™ Motion Picture BoxPH400A1-N2J-26BC2CC

400A 120/208 VAC, (5) 16 Series Cam-type, Single Pole Males (Inlets) to (6) 100A Stage Pin Receptacles, Feed Thru, CineBox™

600 Amp Powerstation Load Master with Adjustable Output Circuits, Weather Resistant

600 Amp Powerstation Load Master with Adjustable Output Circuits, Weather ResistantPH600G3-N1J-14AV

600A 600Y/347 VAC, (2) sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

600 Amp Powerstation Load Master with Adjustable Output Circuits, Weather Resistant

600 Amp Powerstation Load Master with Adjustable Output Circuits, Weather ResistantPH600G3-N1J-14AV-BOY

600A 600Y/347 VAC, (2) sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

600 Amp Powerstation Load Master with Adjustable Output Circuits, Weather Resistant

600 Amp Powerstation Load Master with Adjustable Output Circuits, Weather ResistantPH600G3-N1J-14AV-BBB

600A 600Y/347 VAC, (2) sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

60kW Airforce Style Power Distribution Box

60kW Airforce Style Power Distribution Box6110-01-237-4637

Distributes power to smaller distribution units, environmental control units, portable lights and for expeditionary applications including base camps.

800 Amp Power Station Load Master with Adjustable Output Circuits, Weather Resistant

800 Amp Power Station Load Master with Adjustable Output Circuits, Weather ResistantPH800G3-N2J-31AV1AX1AZ

800A 600Y/347 VAC, (2) Sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) Sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Feed Thru, Power Station

800 Amp Power Station Load Master with Adjustable Output Circuits, Weather Resistant

800 Amp Power Station Load Master with Adjustable Output Circuits, Weather ResistantPH800G3-N2J-31AV1AX1AZ-BOY

800A 600Y/347 VAC, (2) Sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) Sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Feed Thru, Power Station

800 Amp Power Station Load Master with Adjustable Output Circuits, Weather Resistant

800 Amp Power Station Load Master with Adjustable Output Circuits, Weather ResistantPH800G3-N2J-31AV1AX1AZ-BBB

800A 600Y/347 VAC, (2) Sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) Sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Feed Thru, Power Station

800 Amp Power Station Load Master™ with Adjustable Output Circuits, Weather Resistant

800 Amp Power Station Load Master™ with Adjustable Output Circuits, Weather ResistantPH800G3-N1J-22AV2AX-BBB

800A 600Y/347 VAC, (2) Sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) Sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather Resistant

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather ResistantPH800G3-N1J-13AX

800A 600Y/347 VAC, (2) sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather Resistant

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather ResistantPH800G3-N1J-13AX-BOY

800A 600Y/347 VAC, (2) sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather Resistant

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather ResistantPH800G3-N1J-13AX-BBB

800A 600Y/377 VAC, (2) of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (3) sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather Resistant

800 Amp Powerstation Load Master with Adjustable Output Circuits, Weather ResistantPH800G3-N1J-22AV2AX

800A 600Y/347 VAC, (2) sets of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) sets of (5) 16 Series Cam-type, Single Pole Females (Outlets), Power Station

800A Outdoor PowerRACK™ Load Master (60A - 250A) CAM Output

800A Outdoor PowerRACK™ Load Master (60A - 250A) CAM OutputPH800W3-N2J-33CC2AV2AX

Load Master® Series portable power distribution racks feature outputs with adjustable current ratings to match specific application loads. These cULus Listed portable power distribution racks are designed to provide enhanced safety and durability, as well as unmatched flexibility and convenience for temporary applications where a range of power loads are required and change frequently.

800A Outdoor PowerRACK™ Load Master (60A - 250A) CAM Output

800A Outdoor PowerRACK™ Load Master (60A - 250A) CAM OutputPH800W3-N2J-22AV2AX

Load Master® Series portable power distribution racks feature outputs with adjustable current ratings to match specific application loads. These cULus Listed portable power distribution racks are designed to provide enhanced safety and durability, as well as unmatched flexibility and convenience for temporary applications where a range of power loads are required and change frequently.

800A Outdoor PowerRACK™ Load Master®

800A Outdoor PowerRACK™ Load Master® PH800P3-N1J-22AX4AJ

Load Master® Series portable power distribution racks feature outputs with adjustable current ratings to match specific application loads. These cULus Listed portable power distribution racks are designed to provide enhanced safety and durability, as well as unmatched flexibility and convenience for temporary applications where a range of power loads are required and change frequently.

800A Outdoor PowerRACK™ Load Master® (60A - 600A) CAM Output

800A Outdoor PowerRACK™ Load Master® (60A - 600A) CAM OutputPH800W3-N1J-31AV1AX1AY

Load Master® Series portable power distribution racks feature outputs with adjustable current ratings to match specific application loads. These cULus Listed portable power distribution racks are designed to provide enhanced safety and durability, as well as unmatched flexibility and convenience for temporary applications where a range of power loads are required and change frequently.

800A Outdoor PowerRACK™ Load Master® Spider Distribution + (100A - 250A) CAM Output

800A Outdoor PowerRACK™ Load Master® Spider Distribution + (100A - 250A) CAM OutputPH800W3-N1J-33CC3DW3AV

Load Master® Series portable power distribution racks feature outputs with adjustable current ratings to match specific application loads. These cULus Listed portable power distribution racks are designed to provide enhanced safety and durability, as well as unmatched flexibility and convenience for temporary applications where a range of power loads are required and change frequently.

Bento Box®

Bento Box® "Doghouse"BNA2-3A-6

20A 120/208 VAC, (1) NEMA L21-20 Locking Male (Inlet) to (3) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Feed Thru, Bento™

Hanging Spider Box

Hanging Spider BoxPH050Z3-NMW-26CC1DF

50A 125/250 VAC, (1) California Style CS63 Male (Inlet) to (6) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets) and (1) NEMA L6-30 Locking Receptacle (Outlet), Feed Thru, Backpack

Microgrid Feeder Box

Microgrid Feeder Box616-5003-0171

The AMMPS Microgrid main control unit housing most electronics and electrical control.

616-5003-0171 Olive Green, 616-5003-0172 Tan

Microgrid Kit

Microgrid Kitmicrogrid-full-kit

The Lex Microgrid Kit is designed to automatically start and stop Advanced Medium Mobile Power Sources (AMMPS) generator sets (30kW or 60kW) in pairs of two based on power demand. Connecting (3) Kits together will provide for a Ring Bus Microgrid for up to six generators.

AMMPS Microgrid Kit cuts fuel consumption dramatically while also load balancing between generators for optimum efficiency.

PDISE  : Electrical Distribution System M40 Amp/Phase

PDISE : Electrical Distribution System M40 Amp/Phase 13229E6353

Electrical Distribution System M40 Amp/Phase (A/P): The M40 is a 120/208V, three phase, Electrical Distribution System. It has one (1) three-phase 40 A/P input circuit with one (1) feed-through; and twelve (12) 20 Amp, single-phase output circuits. The system includes a pigtail, distribution cables, extension cables, Ground Fault Circuit Interrupter (GFCI) cables, and household type, duplex receptacle.

13229E6353 (System), 13229E6345 (Unit)

PDISE : 200 Amp System

PDISE : 200 Amp System 13229E6350

Electrical Feeder System M200 Amp/Phase (A/P): The M200 is a 120/208V,three phase, Electrical Feeder System. It has one (1) three-phase, 200 A/P input circuit with three (3) 100 A/P, four (4) 60 A/P and one (1) 20 A/P output circuits. The system also includes a pigtail and feeder cables.

13229E6350 (System), 13229E6300 (Unit)

PDISE : Electrical Distribution System M60 Amp (System)

PDISE : Electrical Distribution System M60 Amp (System)13229E6352

Electrical Distribution System M60 Amp: The M60 is a 120V, single-phase, Electrical Distribution System. It has one (1) 60A input/output circuit with six (6) 20 Amp output circuits. The system includes a pigtail, distribution cables, extension cables, GFCI cables, and household type, duplex receptacle.

13229E6352 (System), 13229E6335 (Unit)

PDISE : Electrical Utility Assembly M46

PDISE : Electrical Utility Assembly M4613226E7046

Electrical Utility Assembly M46: The M46 Utility Assembly is similar to wall outlets in a fixed facility. The M46 comes in a transit container that contains branch circuit assembly, cables, lights, GFCI cables and standard household type duplex receptacles for plugging the electrical load. It could be emplaced within tents, shelters or building.

PDISE : M100 Amp/Phase

PDISE : M100 Amp/Phase13229E6351

Electrical Feeder System M100 Amp/Phase (A/P): The M100 is a 120/208V,three phase, Electrical Feeder System. It has one (1) three-phase, 100 A/P input circuit with one (1) 100A/P feed-through; two (2) 60 A/P, two (2) 40 A/P and two (2) 20 A/P output circuits. The system also includes a pigtail and feeder cables.

13229E6351 (System), 13229E6325 (Unit)

The PCI Boxes

The PCI Boxes616-5007-0172

The AMMPS Microgrid interface control box

616-5007-0172 Tan, 616-5007-0171 Olive Drab Green

Transfer Switch

Transfer Switch 613-5001-0162

Manual & Automatic Military Grade Transfer Switches are used as a means to safely switch between prime and standby power generation sources in order to provide a secure power supply to crucial loads. The transfer switch allows the user to start up a standby generator when the primary power source is not available or shut down for maintenance.

USMC MEPDIS-R

USMC MEPDIS-R "BOO Box" 30kW ECU Power Distribution BoxDB100MA-P1021Q-01S3

100 Amp Military Style with Pin & Sleeve Receptacles

USMC MEPDIS-R 100kW Distribution Box

USMC MEPDIS-R 100kW Distribution BoxDB350MA-P2WAS3

800 Amp Military Style with Cam-Type and Pin & Sleeve Receptacles

USMC MEPDIS-R 15kW Distribution Box

USMC MEPDIS-R 15kW Distribution BoxDB-60MA-F22QS3

120 Amp Military Style with Pin & Sleeve Receptacles

USMC MEPDIS-R 300kW Distribution Bo

USMC MEPDIS-R 300kW Distribution BoDB350MA-P2WQS3

1200 Amp Military Style with Cam-Type and Pin & Sleeve Receptacles

USMC MEPDIS-R 30kW Distribution Box

USMC MEPDIS-R 30kW Distribution BoxDB100MA-P22QS3

200 Amp Military Style with Pin & Sleeve Receptacle

USMC MEPDIS-R 5kW Indoor Box with Cord Sets and Spare Plugs

USMC MEPDIS-R 5kW Indoor Box with Cord Sets and Spare PlugsDB-30NA-AQQ-S3

30 Amp Military Style with GFCI Duplex Receptacles

USMC MEPDIS-R 5kW Outdoor Box with Cord Sets and Spare Plugs

USMC MEPDIS-R 5kW Outdoor Box with Cord Sets and Spare PlugsDB-30NA-A22-S3

30 Amp Military Style with Pin & Sleeve Receptacles

USMC Tactical Water Purification System Box (TWPS)

USMC Tactical Water Purification System Box (TWPS)DB200M2C-P3S415-S3

400 Amp Military Style with Pin & Sleeve

WeldingRack 6-Pack to Arktite Receptacles

WeldingRack 6-Pack to Arktite ReceptaclesWR6A-7SM-FG26FW6LD-R

80A 600Y/480 VAC, PRIMARY, (1) 100A 600 VAC Pin and Sleeve Male (Inlet) to (6) NEMA 60A Arktite Locking Receptacles; 208Y/120VAC, SECONDARY, (6) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets), Welding Rack

WeldingRack 6-Pack to Locking Receptacles

WeldingRack 6-Pack to Locking ReceptaclesWR6A-7SM-FG26DZ6LD-R

80A 600Y/480 VAC, PRIMARY, (1) 100A 600 VAC Pin and Sleeve Male (Inlet) to (6) NEMA 50A Locking Receptacles; 208Y/120VAC, SECONDARY, (6) NEMA 5-20 (Edison) GFCI Straight Blade Receptacles (Outlets), Welding Rack

Lex Products offers a full range of portable power distribution units including boxes, boards and panels, specifically engineered for indoor and outdoor use. Being that Lex Products is a leading North American manufacturer of innovative power distribution systems and lighting solutions for demanding markets including industrial, military and entertainment, all products are subjected to rigorous testing and designed to meet and exceed the strictest safety codes. Lex Products distribution boxes range from 20-800 Amps and are known for their unprecedented durability, safety and reliability. Whether you need a power distribution box for backup power, emergency relief or indoor/outdoor events, Lex Products has you covered.

Frequently Asked Questions

Rubber enclosures are resistant to rust, corrosion, and denting. The enclosure is resistant to mechanical shock, and impacts which increases the protection of the internal component’s vs other enclosure materials. The rubber enclosure allows more compact layout of components allowing the box to be smaller compared to a metal equivalent.

Definitions as specified in UL 50E:

  • TYPE 1 – Enclosures constructed for indoor use to provide a degree of protection to personnel against access to hazardous parts and to provide a degree of protection against ingress of solid foreign objects (falling dirt).
  • TYPE 3R – Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection against ingress of solid foreign objects (falling dirt); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, and snow); and that will be undamaged by the external formation of ice on the enclosure.
  • TYPE 3X – Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection against ingress of solid foreign objects (falling dirt and windblown dust); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, and snow); that provides an increased level of protection against corrosion; and that will be undamaged by the external formation of ice on the enclosure.

This is a safety practice commonly used in the Entertainment industry. Reversing certain cam connections makes it less likely that a ground or neutral would be mistaken for a phase. While usually only found in Entertainment equipment, it is neither an agreed upon practice within the industry nor is it required by Underwriters Laboratories (UL) or the National Electrical Code (NEC).

Cams are colored as a convention to Identify phases, (red black and blue for 120/240 VAC and neutral and ground wires. In the US NEC, only green and white colors are called out for ground and neutral. Red black and blue and conventions for phase colors at 120/240VAC. Brown Orange and Yellow are conventions for 277/480 VAC.
